AT751U
To acquire the best quotation for your desired product, kindly contact us through e-mail or our contact form.
Blank: octi-cam assembled for standard travel
stop adjustment
K: octi-cam assembled for lock-out capability
(stroke adjustment limited at +/- 5°).
Blank: for standard actuator
R50: 50% travel stop limitation (45° up to 90°)
R100: 100% travel stop limitation (0° up to 90°)
FA: fast acting
FM: fail mid 180° rotation
3P: 3 position (only for spring return)
3PD: 3 position (both for spring return and double acting)
HC: hydraulic damper
TS: top smart connection
Blank: actuator with standard seals suitable for -40°C
(-40°F) to 80°C (+176°F)
HT: actuator construction suitable for -15°C (+5°F) to
150°C (+302°F)
LLT: actuator construction suitable for -55°C (-67°F) to
80°C (+176°F)
Blank: standard assembly type ST, clockwise to close
(spring to close) and close indication at air failure condition (or with pressurized port 4 for double acting) for in
line mounting.
STR: clockwise to close (spring to close) and close indication at air failure condition (or with pressurized port 4
for double acting) for across line mounting.
LF: counterclockwise to close (spring to open) and open
indication at air failure condition (or with pressurized
port 4 for double acting) for across line mounting.
LFR: counterclockwise to close (spring to open) and
open indication at air failure condition (or with pressurized port 4 for double acting) for in line mounting.
ISO 5211 Flange Models
PT 045 PT 050 N PT 100 PT 200 PT 250 PT 300 PT 350 PT 400 PT 450 PT 500 PT 550 PT 600 PT 650 PT 700 PT 750 PT 800 PT 1000
TYPE
F03 F04 F05+F07+F10+F12 F14 F16 F25 F30
ISO 5211 Square dimensionsand type available
9DS 11DS 14DS 17DS 22DS 27DS 36DS 46DS 55DS 75DS
9SQ 11SQ 14SQ 17SQ 22SQ 27SQ 36SQ 45SQ 55SQ 75SQ
